Synergy H1 Hybrid Multi-Mode Microplate Reader: Comprehensive Introduction

The BioTek Synergy H1 Hybrid Multi-Mode Microplate Reader is a versatile and modular microplate detection system designed for a wide range of life science, pharmaceutical, biotechnology, molecular biology, biochemistry, and cell research applications. Developed by BioTek and now part of the Agilent BioTek product portfolio, the Synergy H1 combines monochromator-based optics and filter-based optics in a single instrument. This hybrid optical design provides researchers with both wavelength flexibility and excellent detection performance.

The Synergy H1 is designed to support multiple detection technologies, making it suitable for laboratories that need more than conventional absorbance measurements. Depending on the configuration, the system can perform absorbance, fluorescence intensity, fluorescence polarization, luminescence, time-resolved fluorescence, TR-FRET, and BRET measurements. This multifunctional design can help laboratories reduce the need for several dedicated microplate instruments.

Hybrid Optical Technology

One of the main features of the Synergy H1 is its hybrid optical system. The monochromator provides flexible wavelength selection and is particularly useful when researchers need to select specific excitation and emission wavelengths. The filter-based optical system provides dedicated optical configurations for applications requiring high sensitivity and optimized signal detection.

For fluorescence applications, the system can provide variable bandwidth settings, allowing researchers to optimize detection according to the fluorescent dye, assay chemistry, and experimental requirements. Automated Z-focus can also help optimize the reading position for different plate types and sample volumes.

Multiple Detection Modes

The Synergy H1 supports a broad range of microplate-based assays. Absorbance measurements can be used for ELISA, protein assays, nucleic acid quantification, and enzyme activity studies. Fluorescence detection is suitable for fluorescent labeling, cellular assays, molecular biology, and biochemical research.

For more advanced applications, fluorescence polarization can be used for molecular interaction and binding studies. Luminescence detection is suitable for ATP assays, reporter gene assays, luciferase-based applications, and other low-light measurements. Depending on the installed configuration, time-resolved fluorescence and TR-FRET can also be used for sensitive biochemical and drug-discovery applications.

Microplate Compatibility

The Synergy H1 supports a wide variety of microplate formats, including 6-, 12-, 24-, 48-, 96-, and 384-well plates. This flexibility allows the instrument to be used for both small-scale experiments and higher-throughput screening.

The system can also work with Take3 and Take3 Trio microvolume plates for low-volume nucleic acid and protein measurements. These microvolume capabilities can reduce sample consumption and are particularly useful when sample quantities are limited.

Temperature and Shaking Control

Temperature control is an important feature for kinetic and cell-based experiments. Depending on the configuration, the Synergy H1 can provide temperature control up to 70°C. The system also offers different shaking modes, including linear, orbital, and double-orbital shaking, which can help maintain sample homogeneity during kinetic measurements.

Optional CO₂ and O₂ control capabilities can further expand the system's application range for cell-based experiments. These environmental-control functions can help maintain appropriate experimental conditions during extended measurements.

Software and Automation

The Synergy H1 can be operated using Gen5 software, which provides functions for instrument control, assay setup, data acquisition, data processing, and report generation. Researchers can create measurement protocols and customize data-analysis workflows according to specific experimental requirements.

The instrument can also be integrated with laboratory automation platforms. Depending on the configuration, it can work with automated microplate handling and incubation systems, making it suitable for laboratories that need to increase sample-processing efficiency.

Main Applications

The Synergy H1 can be used in many areas, including:

• ELISA and immunoassays

• DNA and RNA quantification

• Protein assays

• Fluorescence analysis

• Fluorescence polarization

• ATP detection

• Reporter gene assays

• Cell viability and proliferation studies

• Cytotoxicity testing

• Enzyme kinetics

• Drug discovery

• High-throughput screening

• Molecular interaction studies

• TR-FRET and BRET assays

• Cell-based kinetic experiments

Main Product Specifications

Conclusion

The BioTek Synergy H1 Hybrid Multi-Mode Microplate Reader combines multiple detection technologies with flexible optical configuration in a single platform. Its hybrid monochromator and filter-based optical design makes it suitable for both routine microplate measurements and more advanced fluorescence, luminescence, and molecular-assay applications.

For laboratories involved in pharmaceutical research, biotechnology, molecular biology, cell research, or drug discovery, the Synergy H1 provides a flexible solution for handling different assay formats. When purchasing a used or refurbished Synergy H1, it is important to confirm the exact configuration, installed optical modules, software, temperature-control functions, gas-control options, and reagent injectors, because these options can vary between individual instruments and directly affect the available applications.
